MO17 Spike Mount

Spike Mount

Stainless steel ground spike for ground mounted lighting applications. Can be used with low voltage lighting fixtures.

  • Heavy walled stainless steel spike will not corrode.
  • Portable design for easy installation of low voltage lighting fixtures.
  • Available with optional stem riser in lengths of 3”, 6”, or 12” to raise lighting fixture above foliage.

  • WRITTEN SPECIFICATIONS

    Spike:

    Spike made from corrosion resistant 316 Stainless Steel. Spike Contains a 1/2” NPS threaded mounting hole.

    Stem:

    Stems are machined from 6061-T6 aluminum, C36000 brass, or 304 stainless steel; and are threaded 1/2” NPS on both ends. Stem option available in lengths of 3”, 6”, and 12”.

    Finish:

    TGIC thermo set polyester powder coat paint available in 14 standard colors. On aluminum model, finish is applied over a corrosion resistant, hexavalent chromium free, RoHS compliant coating. Aluminum model available in one additional metal finish: Clear Anodized. Brass model available in three additional metal finishes: Natural, Polished, and Aged. Stainless steel model available in three additional metal finishes: Natural, Polished, and Brushed.

  • Downloads

    Type Name File size
    MO17 Specification Sheets 412.1 KB
    MO17 Installation Instructions 353.1 KB

  • Photos
